Enerpac S1500 Square Drive Hydraulic Torque Wrench

Square Drive (in): 3/4

Nominal Torque Rated At: 10,000 psi 690 bar

Maximum Torque Output (Ft.lbs): 1440

Maximum Torque Output (Nm): 1952

Minimum Torque Rated At: 1000 psi 69 bar

Minimum Torque (Ft.lbs): 144

Minimum Torque (Nm): 195

Maximum Operating Pressure (psi): 10,000

Weight (lbs): 7

Safety and Performance:
-Compact, high-strength single-body construction provides a small operating radius without sacrificing endurance.
-35 degree rotation angle and rapid return stroke for fast operation.
-Tough manifold design with added safety feature for enhanced operator safety.

Simplicity:
-360 degree click-on reaction arm with quick release lever provides easier handling, even when wearing gloves.
-Includes robust handle which mounts on both sides of tool for extra maneuverability.
-Push button square drive release for quickly reversing the square drive for tightening or loosening.

Versatility:
-Available with optional enhanced tilt and swivel TSP300 manifold for horizontal and vertical maneuverability, with greater durability*

Accuracy:
-Constant torque output provides accuracy of +/-3% across full stroke.
-Optional Angle-of-Turn Indicator provides measurement of rotation.

Calibration Certificate:
-Shipped complete with a calibration certificate.

ATEX certified:
-CE-ATEX certified for safe use in explosive environments.
